An Analysis of Dormant Autonomous System Exploitation in Backbone Internet Infrastructure
How Unassigned Addressing Created a New Attack Vector
presented by Backwater Forensics
How Unassigned Addressing Created a New Attack Vector: An Analysis of Dormant Autonomous System Exploitation in Backbone Internet Infrastructure
Backwater Forensics | Lu Anne Esposito, MS Digital Forensic Science | Draft — 2026-07-09
Status: Working draft. All eight sections in progress/complete.
1. Executive Summary
Autonomous System (AS) numbers that go dormant after a carrier acquisition, bankruptcy, or internal retirement are conventionally treated as administrative debris — bookkeeping left uncorrected, not a security concern. This paper argues that treatment is wrong for a specific, testable reason: dormant ASN space with no accountable current operator is address space with no one positioned to notice or contest unauthorized use of it, and that gap is not merely untidy, it is exploitable. This is not a novel theoretical claim; the technique is independently documented in prior academic research (Testart et al., 2019; Nemmi et al., 2021) and by network-security researchers tracking real-world cases (Guilmette, 2018; Madory, 2018). This paper’s contribution is a sustained, case-study-depth investigation of the pattern operating against real backbone infrastructure, built on a six-year arc from on-the-ground observations to a confirmed, evidence-graded finding set.
Methodology. The investigation applies a null-hypothesis-first standard throughout: any candidate ASN is presumed to reflect ordinary post-acquisition administrative lag until the evidence clears a specific bar (Section 2.4, Section 3). That bar is a five-tier confidence framework (Inferred, Digital Recon Affirmed, Remote Forensic Confirmed, Ground Conditions Confirmed, Active Exploit Confirmed) and a three-part digital validation pipeline — passive DNS fingerprinting, RDAP authorization checks, and BGP routing/upstream analysis — with confirmation requiring at least one validation level to independently clear its own evidentiary standard.
Findings. Applied to a 24-ASN evidence base, this standard cleared roughly as many candidates as administrative lag as it confirmed as anomalous — a null hypothesis doing real analytical work rather than functioning as a formality (Section 4.2). The confirmed cases include a specific, repeatable cross-ASN signature predicted by the thesis: the same non-carrier secondary-market sub-allocator (Cloud Innovation Ltd / LARUS-SERVICE-MNT) appearing in the dormant space of two unrelated carrier ASNs — AS11427 (Charter/TWC lineage) and AS7029 (Windstream lineage) — with no acquisition-history explanation connecting them (Section 4.1). A separate case, AS7046, demonstrates that the underlying vulnerability outlives any single occupant: address space nominally belonging to a legacy Verizon Business/UUNET customer ASN, never brought under accountable current stewardship, hosted a banking-malware command-and-control domain across two independently confirmed blocks two months apart, with a documented disruption in between that did not resolve the underlying condition (Section 4.3).
Impact. For end users, the consequence of this structural gap is not abstract: inherited IP reputation from unrelated prior tenants, routing paths through international infrastructure inconsistent with a domestic subscriber’s reasonable expectations, and — in the AS7046 case — direct co-location with active malicious infrastructure inside space nominally belonging to a legitimate carrier customer (Section 5). In every documented case, the common structural cause is the same: no party is accountable for the space, so no clear remediation path exists when something goes wrong.
Contribution and open question. This paper’s findings independently corroborate a pattern separately identified in academic literature (Testart et al., 2019; Nemmi et al., 2021; NIST, 2019) located only after this investigation’s methodology and empirical work were substantially complete (Section 2.2) — convergent validity from two unrelated efforts, not a study designed around prior work. The paper closes by raising, without resolving, a question its own evidence surfaced during drafting: when disclosure of a vulnerable ASN results in a period of quiet, is that durable remediation of the stewardship gap, or a temporary lull before the same space is reoccupied? AS7046’s own history — disrupted once, reoccupied twice since — argues for skepticism toward any single quiet snapshot, and toward longitudinal tracking as the next step this line of research needs (Section 6.3).
2. Thesis and Principles of the Research
2.1 Origin of the Inquiry
This investigation began as a set of on-the-ground and online observations directed at specific victims. Those early observations are not themselves evidence for the argument this paper makes — per this project’s evidentiary standard, physical and single-source observations are discovery triggers, not findings — but they are the reason a backbone-infrastructure investigation was opened at all. The zoom-in they prompted led to a broader question: was the routing behavior observed around those cases idiosyncratic to those targets, or was it an instance of a general, repeatable condition in how the internet’s backbone handles address space that carriers have stopped actively managing?
Over six years, that question narrowed from “something is wrong with this specific routing” to a testable, general claim about a structural property of Autonomous System (AS) allocation and BGP routing: that unassigned, dormant, or administratively orphaned address space is not merely untidy bookkeeping, but a distinct and exploitable attack surface.
2.2 Thesis
Dormant and unassigned Autonomous System space constitutes a persistent, exploitable attack vector in backbone internet infrastructure — separate from and not fully explained by ordinary post-acquisition administrative lag — because the absence of active stewardship removes the one control (an attentive registrant) that would otherwise detect and contest unauthorized routing.
This is not a novel theoretical claim in isolation. It is independently documented in the academic literature: Nemmi et al. (2021) identify dormant ASNs “suddenly waking up” to hijack address space, citing AS10512 — allocated for 17 years, active in BGP for only 31 days, during which it hijacked 60 /16 prefixes including space belonging to Spectrum (AS11426). Testart et al. (2019) trained a classifier that flagged 934 ASes with behavioral similarity to known serial hijackers. NIST SP 800-189 formally names both “announcement of unallocated address space” and “prefix squatting” as interdomain routing attack patterns. This paper’s contribution is not to establish that the technique exists — the literature already does that — but to document its operation, at case-study depth, against real backbone infrastructure over a sustained investigation, and to show a specific repeatable signature: the same non-carrier secondary-market sub-allocator appearing across multiple, otherwise-unrelated dormant carrier ASNs.
A note on chronology, stated plainly for methodological honesty. This investigation’s methodology, hypothesis, and the confirmed findings reported in Section 4 were developed and largely completed before this academic literature was located. The literature above was found during the drafting of this paper — after the empirical work, not before it — and its role here is independent corroboration that this project’s findings match a pattern separately documented by academic researchers using different methods and a different dataset, not a framework this investigation was designed against. That distinction matters: a finding that happens to match prior literature discovered afterward is evidence of convergent validity, not evidence that the investigation was built to reproduce a known result. The remainder of this paper is written to keep that distinction clear — the literature is cited as corroboration, never as a source the methodology was derived from.
2.3 What This Paper Is Not Arguing
Per the Designation Gate applied throughout this project’s methodology, no actor or entity is named as culpable in this paper unless the evidentiary bar for that claim is independently cleared and documented. This paper describes infrastructure conditions — what address space is being announced, by what AS, with what (or absent) registration authority — not intent, and not attribution to a named actor beyond what ARIN/RDAP records establish as a matter of public record. Where a carrier’s own ASN shows an anomaly (e.g., Charter appearing under three different status classifications across its ASN portfolio), the paper’s default explanation is administrative lag until the evidence clears the higher bar described in Section 2.4.
2.4 The Null Hypothesis This Paper Had to Clear
Large carriers accumulate ASNs through decades of acquisition (TCI → AT&T Broadband → Comcast; Time Warner Cable → Charter; MCI → Worldcom → Verizon Business; Global Crossing → Level 3 → Lumen). A dormant or inconsistently-documented ASN is the expected byproduct of that history, and by itself proves nothing. The working null hypothesis throughout this investigation has been:
H0 — Administrative Lag: Apparent routing anomalies in legacy carrier ASNs are fully explained by ordinary post-acquisition record-keeping delay. No unauthorized third party is routing the space; the registrant’s own network engineering has simply not caught up to ARIN’s records, or vice versa.
H0 is the default explanation for any single anomalous observation in this dataset. It is only set aside for a given ASN when the evidence clears one of the Tier R (Remote Forensic Confirmed) confirmation standards described in Section 3 — not on the basis of the anomaly’s appearance alone. Section 3.4 documents the specific evidentiary bar and gives a worked example (AS10913) of a finding that was tested against H0, found to be H0 after all, and retracted — which the project methodology treats as the process working correctly, not as an error to be minimized.
2.5 Guiding Principles
The research adheres to the following principles, carried consistently across all evidence collection, characterization, and disclosure activity described in Section 3–5:
| Principle | Application |
| Actor-agnostic framing | Findings describe infrastructure conditions (“AS11427 announces prefixes it has no recorded authorization for”), not actors or motive. |
| Evidence-graded claims | Every finding is traceable to a named source, database query, or documented OSINT method, and carries an explicit confidence tier (Section 3.2). |
| Reproducibility | Methodology is public-tool-based (ARIN RDAP, RIPEstat, Robtex) and explicit enough that an independent researcher with the same access could reach the same findings. |
| Partner-oriented disclosure | Carriers and CISA are treated as partners in remediation, not subjects of accusation. Disclosures give carriers a remediation window rather than asserting wrongdoing. |
| Null-hypothesis-first | The benign/administrative explanation is stated and evaluated before any anomaly label is applied (Designation Gate). |
| Cleared findings are retained | A finding that does not hold up (e.g., AS10913, Section 2.4) is documented as a retraction, not deleted — clearing a lead is treated as evidentiary output in its own right. |
3. Experiment Structure, Hypothesis, and Methodology
3.1 Formal Hypotheses
H1 (working hypothesis): A measurable subset of dormant or under-stewarded Autonomous System space is being used to route address blocks without documented authorization from the registrant, and this activity follows a repeatable pattern rather than occurring as isolated, unrelated incidents.
H0 (null hypothesis): Observed anomalies in legacy carrier ASN routing are attributable to ordinary administrative lag following corporate acquisition, with no unauthorized third-party routing activity present.
H1 is accepted for a given ASN only when at least one Tier R confirmation standard (Section 3.4) is independently met. Meeting a lower evidentiary tier (Inferred or Digital Recon Affirmed) is not sufficient to reject H0 for that ASN; it moves the item to the validation queue rather than to a confirmed finding.
3.2 Confidence Tier Framework
All findings in this investigation are graded against a five-tier confidence scale, applied consistently from initial discovery through final characterization:
| Tier | Code | Meaning |
| Inferred | I | Acquisition history predicts a seam condition — not directly observed |
| Digital Recon Affirmed | D | Passive OSINT confirms conditions favorable to the hypothesis |
| Remote Forensic Confirmed | R | PCAP, live BGP behavior, passive DNS, or ARIN/RDAP verification — forensic-grade digital evidence |
| Active Exploit Confirmed | A | Direct, first-hand confirmation of active exploitation — victim report, ISP action, or law enforcement action (including seizure/sinkholing of address space) — analyst-assigned only, never automated |
This paper applies four of the five Backwater Forensics confidence tiers (I, D, R, A). Ground Conditions Confirmed (G) is part of the parent framework but was not a confirmation pathway used in this investigation; backbone/ASN findings moved directly from Tier R (digital) to Tier A (direct law enforcement action, including seizure/sinkholing) with no intervening physical/case-overlap corroboration step.
This paper reports findings at Tier R or above only, consistent with the confirmation standard described below. Lower-tier items (I, D) are described in Section 4 as candidates under monitoring, not as confirmed findings.
3.3 Validation Pipeline
The investigation proceeds through a phased pipeline, moving a candidate ASN from initial discovery to a confirmed disposition:
– Phase A — Initial validation via RIPE/ARIN RDAP lookup (registrant identity, allocation date, basic routing presence) – Phase B — Digital risk assessment (prefix count, pDNS presence, upstream transit relationships) – Phase C — PTR / routing validation (confirmation-grade checks described in 3.4 below)
A candidate ASN is not reported as confirmed until it has passed through Phase C and cleared at least one Tier R standard.
3.4 Tier R Confirmation Standards (Validation Levels 3–5)
*Note on terminology: “Validation Level” (below) refers to which diagnostic test was run in the validation pipeline. It is a separate axis from the confidence tiers (I, D, R, A) defined in Section 3.2 — a finding can pass Validation Level 4 (RDAP) and still only carry Tier R confidence until further corroborated. The two are related but not interchangeable.*
Three independent diagnostic tests are available to move an ASN from PENDING_VERIFICATION to a confirmed status. Any single test meeting its confirmation standard is sufficient to confirm at Tier R; all three meeting standard together constitutes the strongest evidentiary basis.
Level 3 — Passive DNS Fingerprint. Tests whether the ASN’s announced IP space resolves to live carrier infrastructure hostnames, dormant space, or anomalous/foreign hostnames inconsistent with the ASN’s documented carrier history. Confirmed when carrier-infrastructure hostnames resolve from space the ASN has no documented right to announce, or when foreign/anomalous hostnames resolve from ostensibly domestic carrier space. Tooling: asn_pdns_puller.py against RIPEstat (prefix enumeration) and Robtex (passive DNS), no authentication required.
Level 4 — RDAP OriginAS Authorization Check. Tests whether any ASN is authorized by the IP block’s registrant to announce that space. An empty originas field on the ARIN RDAP record means no ASN — including the one currently routing the block — has documented authorization. Confirmed when sampled blocks return originas: [], or when the registrant of record is a non-carrier entity with no documented acquisition chain to the announcing ASN. Data source: ARIN RDAP (public, read-only).
Level 5 — BGP Prefix and Routing Analysis. Tests whether current announced prefix composition and upstream transit relationships are consistent with the ASN’s documented history. Confirmed when international backbone upstreams appear for a domestic-only carrier ASN with no documented international operations, when prefix composition includes geographically inconsistent space, or when two independently dormant ASNs share an identical upstream set (indicating common operational control rather than coincidence). Data source: RIPEstat (public, read-only). A secondary, non-dispositive check cross-references the RIPE Internet Routing Registry (IRR) for a registered routing policy; absence of one is a supporting flag, not independent confirmation.
3.5 Sampling Frame
The candidate population was seeded from a set of geographic nodes (ZIP-code-based) associated with the six-year investigation’s original discovery triggers, subsequently expanded to include university-network nodes as a comparison subset. ZIP-code seeding is used strictly as a sampling method to identify which carrier ASNs serve a given locality for further RDAP/BGP analysis — it is not itself evidentiary, and no physical-location finding is reported in this paper’s scope (Autonomous System routing conditions only, per project scope decision).
The sampling frame grew across three points in the investigation rather than being fixed from the outset. The 2026-05-05 baseline register comprised 19 ASNs, spanning legacy TCI/AT&T Broadband, Adelphia/Insight, Time Warner Cable/Charter, MCI/Worldcom, Global Crossing/Level 3, EarthLink/Internap, and Windstream lineages — chosen because each represents a distinct acquisition chain with a plausible dormancy or stewardship gap. That register was subsequently expanded to 23 ASNs through registry expansion (Section 8.3), and to the paper’s full 24-ASN evidence base with the later addition of AS7046, which entered the investigation through a separate thread — the bybanking.com sinkhole discovery (Section 4.3) — rather than the original acquisition-lineage sampling logic above. The count reported elsewhere in this paper (Executive Summary, Sections 4.0, 4.2, and 8) is this final, fully reconciled 24.
3.6 Corroboration Threshold
A three-independent-hit threshold applies to cyber/network evidence: three independent cyber/network findings (e.g., pDNS anomaly + RDAP gap + shared upstream with another anomalous ASN) confirm a pattern as deliberate rather than coincidental, where a single hit alone would not. This threshold applies only to cyber/network evidence; it does not apply to and is not satisfied by physical/on-the-ground observations, which are excluded from this paper’s evidentiary base by design (Section 3.5).
3.7 Data Sources
| Source | Role | Access |
| ARIN RDAP | Registrant identity, allocation history, originas authorization | Public, read-only |
| RIPEstat | Announced prefixes, routing status, ASN upstream neighbors | Public, read-only |
| Robtex | Passive DNS | Public, read-only |
| RIPE IRR | Routing policy registration (secondary flag) | Public, read-only |
| CISA supplemental filings | Disclosure and correction record for filed findings | Internal case record |
3.8 Methodological Limitation Acknowledged in the Literature
Academic literature located after this investigation’s methodology was developed (see the chronology note in Section 2.2) independently corroborates a limitation this project encountered directly: BGP-activity analysis alone cannot fully distinguish malicious squatting from other causes without administrative allocation context. Nemmi et al. (2021) note that some dormant-ASN awakenings (e.g., 31 ASNs reactivating simultaneously in April–July 2020) were only confirmable as malicious by cross-referencing known-malicious upstream ASNs, not from prefix behavior in isolation. This investigation’s combination of the RDAP originas check and BGP upstream analysis (Section 3.4, Validation Levels 4 and 5) was designed independently and happens to address the same limitation.
4. Findings
4.0 Overview
Findings are organized thematically rather than ASN-by-ASN, consistent with the thesis in Section 2: the paper’s contribution is the *pattern*, not any single ASN’s status. Full per-ASN evidence, dates, and file references are in Section 8. This section draws on that evidence base to make four arguments in sequence: that the cross-ASN signature predicted in Section 2.2 is present in the data; that the null-hypothesis discipline in Section 2.4 actually separated administrative lag from exploitation rather than assuming the answer; that the resulting infrastructure gap has been used for purposes unrelated to the original carrier acquisition (illustrated concretely); and that at least one confirmed law-enforcement operation’s timing coincides with two of this methodology’s own findings — stated as a documented coincidence, not as independent convergence or confirmed coordination.
4.1 The Cross-ASN Signature Holds
Section 2.2 proposed a specific, falsifiable signature distinguishing systematic exploitation from ordinary administrative lag: the same non-carrier secondary-market sub-allocator appearing across multiple, otherwise-unrelated dormant carrier ASNs. That signature is confirmed in one instance and supported by a second, pending independent verification.
AS11427 (TWC-11427-TEXAS, Charter’s own ARIN registration, BGP routing authority unknown) carries a prefix composition of 21% legacy Time Warner Cable space, 77% Cloud Innovation Ltd (Seychelles, AFRINIC secondary-market registrant ORG-CIL1-AFRINIC), and 2% APNIC space under MAINT-SNPL-PK (Pakistan). A subset of that space — the 156.x.x.x range — is AFRINIC ERX: unallocated registry-held blocks being announced with no end-user allocation on record.
AS7029 (Windstream, WINDSTREAM_RECLAIM status following its own reclaim confirmation) is separately associated with a 154.194.16.0/21 block registered to Future Tech Distribution under the same sub-allocator, LARUS-SERVICE-MNT — an association documented in this project’s correction log but not yet independently confirmed by a block-level RDAP query (Section 8.1b); treated here as a supporting data point pending that confirmation, not as an independently verified second instance of the signature.
One carrier ASN — AS11427 — carries a confirmed, RDAP-verified instance of address space from a Seychelles LIR (Cloud Innovation Ltd / LARUS-SERVICE-MNT) routed through its dormant allocation, with no acquisition-history explanation connecting that LIR to Charter/TWC. AS7029’s association with the same sub-allocator is documented in this project’s own correction log but rests on a source that has not yet been independently confirmed by a block-level RDAP query (see the note above and Section 8.1b); it is reported here as a lead consistent with the same pattern, not as a second confirmed instance. If independently confirmed, the two together would represent unrelated carrier ASNs — unrelated acquisition histories (Charter/TWC vs. Windstream), unrelated geographies, unrelated original owners — carrying address space from the same external sub-allocator, which post-acquisition record-keeping delay alone would not explain. Until that confirmation exists, this paper’s falsifiable claim rests on the single verified AS11427 instance; the AS7029 lead is disclosed for transparency and flagged for the next validation pass, not treated as established. This finding is consistent with, and — pending AS7029’s confirmation — would add a case instance to, the “systematic routing vehicle” pattern documented by Nemmi et al. (2021) in dormant-ASN hijacking generally.
4.2 The Null Hypothesis Did Real Work
A methodology that never clears H0 for anything is not rigorous — it is unfalsifiable. Table 4.1 shows the null hypothesis was applied evenhandedly across the 24-ASN evidence base (Section 8), clearing roughly as many candidates as it held.
Table 4.1 *Disposition of Candidate ASNs Against the Administrative-Lag Null Hypothesis*
| Disposition | ASNs | Basis |
| H0 held — cleared as administrative lag / misattribution | AS10913, AS6181, AS2686, AS5650 | Direct RDAP registrant confirmation contradicted the working hypothesis in each case (Section 8: AS10913 retraction, CISA CORRECTION-002; AS6181 Cincinnati Bell/FUSE-NET, corrected pre-disclosure; AS2686/AS5650 confirmed legitimate current operators via RDAP + RIPEstat) |
| H0 rejected — Tier R confirmed third-party exploitation | AS11427, AS7015, AS7046 | Cleared the Tier R confirmation standard (Section 3.4): originas gaps or routing/upstream anomalies indicating unauthorized third-party control inconsistent with documented history |
| H0 rejected — Tier R confirmed, administrative retention anomaly (no third-party control) | AS11426, AS6128 | Carrier retains a redundant or duplicate legacy ASN with no operational handoff to a third party; anomalous relative to documented acquisition history but not evidence of unauthorized routing |
| H0 rejected — analyst-assessed law enforcement activity, Tier R (not independently Tier A) | AS7015, AS7046 | Dark-window timing coincides with INTERPOL Operation Ramz; registry’s own language is “likely law enforcement infrastructure,” not a confirmed seizure — see 4.4 and 8.1a |
| H0 rejected — status conflict, not independently resolved | AS8069 | Active anomaly since the 2026-05-05 baseline (OWNERSHIP_ANOMALY, listed among ASNs requiring disclosure/action) — never cleared. Two later sources disagree on its current label (ZOMBIE-ASN-REGISTRY.db: ACTIVE_MONITOR; asn_source.json: MISATTRIBUTION, frozen 2026-05-06); PeeringDB confirms the registrant (Microsoft Azure Routing Preference) regardless of which label is current. Carried forward as unresolved, not picked one way or the other — see 8.1c |
| Resolved during drafting — corrected, not left pending | AS33363 (→ RETENTION_ANOMALY), AS54396 (→ MISATTRIBUTION) | Register cross-check (ZOMBIE-ASN-REGISTRY.db) caught two stale statuses in this paper’s own earlier draft — see Section 8 entries |
Two of the paper’s clearances — AS10913 and AS6181 — are worth naming specifically because they show the discipline catching itself at different points in the disclosure pipeline. AS10913 was filed to CISA as a confirmed zombie on 2026-05-02 and retracted three days later (CORRECTION-002) — the correction happened, but only after external disclosure. AS6181 was headed for the same filing, built on a full write-up (geography, upstream peers, a 14-year “double migration failure” narrative) — and was caught and corrected internally before it ever reached CISA or FBI. Methodologically these are the same discipline; operationally, the second is the better outcome, since it demonstrates the check working *before* an error reaches an external partner rather than after.
4.3 What Lives in the Gap: AS7046 and bybanking.com
Sections 4.1 and 4.2 establish that unauthorized routing exists and can be distinguished from administrative lag. AS7046 shows what that gap is actually used for once it exists — and by whom is not always the original zombie-routing party.
AS7046 (RFC2270-UUNET-CUSTOMER, registered to Verizon Business under the same organization as legitimate AS701/UUNET) cleared Tier R confirmation on 2026-05-27: sampled IPv6 blocks belonging to federal entities — CFTC-NETWORK, TERRENAP-V6, DOLNET, WIRE-V6, and CMMS-IPV6 (identified in a later re-check, 2026-07-15; its registrant name is consistent with, but not independently confirmed as, the Centers for Medicare & Medicaid Services) — returned originas: [], meaning no ASN, including the one announcing them, carried documented authorization. The ASN’s technical point of contact had been unvalidated by ARIN since 2022-11-02. Routing went dark on 2026-05-19, coincident with the INTERPOL Operation Ramz MENA takedown, and re-emerged and stabilized by 2026-05-22.
A Tier 3 passive DNS run on 2026-06-16 — the first pDNS fingerprint conducted on this ASN in the investigation — returned exactly one notable record: the subdomain 9ve2e267.bybanking.com resolving to 161.162.17.104, inside AS7046’s announced space. An independent Falcon Sandbox report from 2026-02-09 had already flagged bybanking.com as suspicious (threat score 45/100), exhibiting MITRE ATT&CK technique T1204 (user execution via malicious link), TTL-5 fast-flux DNS — a rotation interval far below the 300–3600 second range typical of legitimate infrastructure — and a secondary callback to a Hong Kong-registered IP. Every sandboxed execution rendered a neutral Google search page rather than a phishing payload, a pattern most consistent with traffic being redirected and logged by a controlling party rather than served to its intended victims.
Taken together, this is evidence of federal address space — unauthorized for routing by any entity, per RDAP — being used to intercept and log callbacks from unrelated banking-malware infrastructure. This is not a finding about AS7046’s original zombie-routing operator; it is a finding about what an unaccountable routing gap becomes available for once it exists, independent of who created the gap in the first place. Consistent with the actor-agnostic principle in Section 2.3 and the explicit limits stated in the source finding (Section 8, AS7046 entry), this paper does not identify which federal agency operates the capture point, the identity of the threat actors whose traffic is being captured, or whether the Hong Kong contact is part of the same or a separate operation. What is established is narrower and still significant: the same structural condition this paper’s thesis describes — dormant, unauthorized address space with no accountable current operator — is not a single-purpose vulnerability. It is reusable infrastructure, available to whichever party notices it first.
4.4 Timing Correlation with a Documented External Event
Section 3.2 draws a deliberate distinction between Tier R (digital confirmation) and Tier A (direct law enforcement action). Neither AS7015 nor AS7046 clears Tier A in this paper — an earlier draft overstated AS7015 as a confirmed law-enforcement seizure; that has been corrected (Section 8, 8.1a). What both ASNs share is narrower: their dark-routing and disruption timing coincides with INTERPOL Operation Ramz, a real, externally documented and independently verifiable takedown announced 2026-05-18.
AS7015 was confirmed ZOMBIE_TRANSIT at Tier R on 2026-05-05, then reclassified SINKHOLE_TRANSIT with a dark window and re-emergence spanning approximately 2026-05-19 through 05-22. AS7046’s dark-routing window — identified independently through RDAP and BGP analysis — falls on the same date, 2026-05-19.
This is worth naming precisely rather than overselling. Both assessments rest on the same underlying inference — Tier R digital confirmation (RDAP originas gaps, BGP behavior) plus timing coincidence with one external event — not on two independent methods arriving separately at the same conclusion. That is a materially weaker claim than “law enforcement reached the same ASNs this methodology flagged first,” and this paper does not make that claim. What can be stated is that two ASNs, confirmed anomalous through this investigation’s Tier R digital methodology on separate evidentiary bases (Section 4.1’s cross-ASN signature does not apply to either of these two), both show disruption in the same window as a real, named, externally documented takedown operation. Whether that reflects the same operation, a coincidental timing overlap, or an artifact of how zombie ASN space gets swept up in broader enforcement actions is not established by the evidence in hand.
5. Impact to Users
5.0 Overview
The findings in Section 4 describe an infrastructure condition. This section describes what that condition means for the people whose traffic passes through it — subscribers who have no visibility into which ASN carries their packets, no way to know whether that ASN has an accountable current operator, and no mechanism to opt out of routing through address space with the characteristics documented in Sections 4.1–4.3.
5.1 Inherited Reputation
Address space does not arrive clean. AS11427’s prefix composition includes AFRINIC ERX blocks and Cloud Innovation Ltd secondary-market space with routing and reputation histories entirely disconnected from the Charter subscribers whose traffic may traverse it. A subscriber has no way to know that the IP address assigned to them carries a blocklist history, spam reputation, or prior abuse association accumulated by a completely different, unrelated party before the space was folded into a zombie-routed block. This is a direct, individual harm: legitimate traffic — email, VPN connections, authenticated sessions — can be blocked, flagged, or rate-limited by downstream services relying on IP reputation, for reasons the subscriber has no way to diagnose and no relationship with the responsible party to resolve.
5.2 Anomalous Routing Exposure
Several confirmed zombie ASNs in this investigation’s evidence base show upstream transit relationships inconsistent with their documented domestic customer base — international Tier 1 peers (Telstra, PCCW, SingTel, Arelion) appearing on ASNs that, per their registration history, should carry only regional US traffic. A subscriber whose traffic is routed through such a path experiences this invisibly: added latency, additional international hops, and — more significantly — traffic traversing networks and jurisdictions the subscriber never agreed to and has no reason to expect. This is not a claim that any specific subscriber’s traffic has been intercepted; it is a claim that the routing path itself is inconsistent with what a domestic residential or business subscriber should reasonably expect, and that inconsistency is invisible to the person experiencing it.
5.3 Co-Located Malicious Infrastructure
Section 4.3 documented banking-malware C2 infrastructure resolving into address space nominally belonging to a Verizon Business/UUNET legacy customer ASN. This is the clearest, most concrete user-facing harm this investigation identified: address space that a legitimate business customer’s infrastructure planning would reasonably assume is either in active use by that customer or properly retired is, in practice, available for use by unrelated third parties — in this case, infrastructure supporting a malware campaign with no connection to the ASN’s nominal owner. Any monitoring, security tooling, or threat-intelligence system that associates network behavior with the announcing ASN or its registered organization risks misattributing this activity to Verizon Business/UUNET, an organization with no operational connection to it.
5.4 Loss of Accountability
Across every confirmed finding in Section 4, the common thread is not malicious intent on the part of the original carrier — it is the absence of anyone accountable for the space at all. A subscriber experiencing a routing or security problem traceable to zombie-routed address space has no clear party to contact: not the original carrier (which no longer operates the space and, in several cases documented in Section 8, may not know it is still routing), not the acquiring carrier (which has no visibility into space it never took over), and not ARIN (which maintains the registration record but has no operational role in troubleshooting). This is the structural harm underlying every specific example above: address space with no accountable operator produces no clear remediation path when something goes wrong, regardless of whether “something going wrong” is a reputation problem, a routing anomaly, or hosted malicious infrastructure.
6. Conclusion
6.1 What This Paper Established
The thesis stated in Section 2.2 — that dormant and unassigned Autonomous System space constitutes a persistent, exploitable attack vector separate from ordinary administrative lag — is supported by the evidence in Section 4, with the specific evidentiary bar set in Section 2.4 (the administrative-lag null hypothesis) applied consistently rather than assumed away. The cross-ASN signature predicted in Section 2.2 — the same non-carrier secondary-market sub-allocator appearing across multiple, otherwise-unrelated dormant carrier ASNs — is present in the confirmed data (Section 4.1). The null hypothesis did real analytical work rather than functioning as a formality: roughly as many candidate ASNs were cleared as administrative lag as were confirmed as anomalous (Section 4.2, Table 4.1), and two of those clearances (AS10913, AS6181) demonstrate the methodology catching its own errors at different points in the disclosure pipeline — one after external filing, one before. AS7046 (Section 4.3) demonstrates that the structural condition this paper describes is not a single-purpose vulnerability tied to its original cause; it is reusable infrastructure, available to whichever party — carrier successor, law enforcement, or unrelated criminal actor — notices the gap first.
6.2 Limitations
This paper’s evidence base is drawn from a single investigation’s sampling frame (Section 3.5), seeded from specific geographic nodes and subsequently expanded, not from a systematic census of all ARIN-region ASNs. The confirmed findings should be read as case-study depth on a real, bounded set of carrier ASNs, not as a population-level estimate of how common this pattern is across the internet’s full address space. The methodology itself has a documented limitation (Section 3.8): BGP activity and RDAP authorization gaps alone cannot always distinguish malicious squatting from other administrative causes without the kind of cross-referencing this investigation performed — a limitation independently corroborated by academic literature located after this investigation’s methodology was already in place (Nemmi et al., 2021; see the chronology note in Section 2.2). Finally, as discussed in Section 4.4 and corrected during this paper’s own drafting process, the distinction between “law enforcement disrupted an occupant of vulnerable space” and “law enforcement remediated the underlying vulnerability” is not one that passive digital methods can resolve on their own — and this paper is explicit that it has not resolved it for the cases where the question arose.
6.3 A Further Question This Paper Raises But Does Not Answer
AS7046’s evidence chain (Section 4.3, Section 8) surfaces a question this paper is not positioned to answer with the data in hand: when this investigation’s disclosures result in an ASN’s unauthorized routing going quiet, does that represent durable remediation of the underlying stewardship gap, or a temporary lull before the same gap is reoccupied? AS7046 was disrupted once, coincident with a real external law-enforcement operation, and was reoccupied twice since, using two different address blocks. A single quiet snapshot — even a 30-day one — is not, on its own, evidence that the vulnerability was fixed rather than merely unused at that moment. Answering this properly requires longitudinal tracking of reported ASNs against their subsequent routing behavior over months, not a single before/after comparison. If that tracking shows some disclosures produce durable remediation while others produce only temporary disruption followed by reoccupation, that would be a stronger and more falsifiable version of this paper’s thesis than anything established here: not simply that unassigned address space is exploitable, but that disclosure alone is frequently insufficient to close the gap that makes it exploitable. This paper flags the question; it does not have the data to answer it.
6.4 Closing
Unassigned and dormant Autonomous System space is not a bookkeeping curiosity left over from decades of carrier consolidation. It is address space with no accountable current operator, and the evidence in this paper shows that gap gets used — by secondary-market IP brokers routing space with no legitimate end-user allocation, by unrelated criminal infrastructure taking advantage of a carrier customer ASN nobody is watching, and, at least once, by whatever disrupted that infrastructure in turn. The internet’s routing system has no built-in mechanism that requires an ASN to prove it is still accountable to anyone. Until it does, this attack surface will keep being available to whoever finds it next.
7. Bibliography
Guilmette, R. F. (2018, June 26). *AS3266: BitCanal hijack factory, courtesy of Cogent, GTT, and Level3* [Mailing list message]. NANOG. https://mailman.nanog.org/pipermail/nanog/2018-June/096034.html
Kumari, W., Bush, R., Schiller, H., & Patel, K. (2015). *Codification of AS 0 processing* (RFC 7607). Internet Engineering Task Force. https://doi.org/10.17487/RFC7607
Madory, D. (2018, July 11). *Shutting down the BGP hijack factory*. Dyn Blog. https://dyn.com/blog/shutting-down-the-bgp-hijack-factory/
National Institute of Standards and Technology. (2019). *Resilient interdomain traffic exchange: BGP security and DDoS mitigation* (NIST Special Publication 800-189). U.S. Department of Commerce. https://doi.org/10.6028/NIST.SP.800-189
Testart, C., Richter, P., King, A., Dainotti, A., & Clark, D. (2019). Profiling BGP serial hijackers: Capturing persistent misbehavior in the global routing table. In *Proceedings of the Internet Measurement Conference (IMC ’19)* (pp. 420–434). Association for Computing Machinery. https://doi.org/10.1145/3355369.3355581
Nemmi, E. N., Sassi, F., La Morgia, M., Testart, C., Mei, A., & Dainotti, A. (2021). The parallel lives of Autonomous Systems: ASN allocations vs. BGP. In *Proceedings of the ACM Internet Measurement Conference (IMC ’21)*, 19 pages. Association for Computing Machinery. https://doi.org/10.1145/3487552.3487838
*Note: verified 2026-07-30 against the original ACM PDF (analyst-provided). Two corrections applied: (1) the author list was previously copied from the 2019 Testart et al. entry — actual 2021 authors are Nemmi, Sassi, La Morgia, Testart, Mei, and Dainotti (Testart is 4th author, not 1st). Per analyst direction (2026-07-30), all six in-text citations of this source (Sections 2.1, 2.2, 2.3, 3.8, 4.1, 6.3) have been updated from “Testart et al. (2021)” to “Nemmi et al. (2021)” to match; the 2019 paper (genuinely first-authored by Testart) is unaffected and still cited as “Testart et al. (2019)” throughout. (2) DOI confirmed correct (10.1145/3487552.3487838); ACM lists this as a 19-page article, not a continuous page range — “page range” as originally requested does not apply to this citation format. The NIST SP 800-189 citation remains unverified and is out of scope for this pass.*
8. Evidence Log
*Backwater Forensics | Culled for peer review 2026-07-29: full per-file evidence tables retained only for the six ASNs that move or control the paper’s arguments (Sections 4.1–4.4); all other ASNs summarized to one row each. 210 unique evidence files remain represented in aggregate across this log (per-ASN sections plus the batch/multi-ASN summary in 8.2), deduplicated for files cross-referenced under more than one ASN. Full per-file hashes for every file — summarized or not — remain in SHADOW_MARKET_FILE_HASHES.txt, which is unaffected by this cull. 6 files excluded as out-of-scope (analyst-scoped, dated 2026-07-11) and 4 files (AS702/AS2686/AS5650/AS14905 pDNS run) confirmed in-scope as comparison/control evidence.*
8.1 Corrections on File
| ASN | Correction | Filed as | Status |
| AS10913 | TRUE ZOMBIE (filed 2026-05-02) -> LEGITIMATE_SUCCESSOR | CISA CORRECTION-002 | Retracted post-disclosure |
| AS11427 | CLEAN (Phase A) -> THIRD_PARTY_CONTROL / ZOMBIE | CISA CORRECTION-001 | Corrected post-disclosure |
| AS6181 | TRUE ZOMBIE (Insight) -> FALSE_POSITIVE (Cincinnati Bell/FUSE-NET) | Not filed — caught pre-disclosure | Corrected in baseline register 2026-05-05, before any CISA/FBI transmission. Internal record FALSE-POSITIVE-ALERT-AS6181-CISA-SUPPLEMENT-VRF26-04-TPWXX.txt documents the correction on Backwater Forensics’ own side; its CISA-styled filename reflects the intended-format convention, not an actual transmission. No retraction required. |
8.1a Analyst-Assessed Law Enforcement Activity (not Tier A confirmed — see note)
| ASN | Finding held | Assessed event | Status |
| AS7015 | ZOMBIE_TRANSIT (Tier R, 2026-05-05) → SINKHOLE_TRANSIT (Tier R) | Dark window and re-emergence timing coincide with INTERPOL Operation Ramz (~2026-05-19/22, per BACKBONE-INVESTIGATION-LOG-v2.md I-032) | Corroborating, not independently Tier A. The registry’s own language is “likely law enforcement infrastructure (INTERPOL/FBI)” — an analyst assessment based on timing correlation, not a confirmed seizure notice, court filing, or direct LE contact. Held at Tier R. Corrected from an earlier draft of this paper that overstated this as a confirmed Tier A finding. |
8.1b Full Evidence — Load-Bearing ASNs
The six ASNs below carry direct citations in Sections 4.1–4.4 and retain full per-file evidence tables.
AS6181 — FUSE-NET — Cincinnati Bell Telephone Company LLC
Status: FALSE_POSITIVE | Case ref: CASE-008 | Confidence tier: R | Evidence files: 3
CORRECTED PRE-DISCLOSURE. RDAP (AS6181-DEETS.txt, 2026-07) confirms registrant is Cincinnati Bell (FUSE-NET), not Insight. Attribution error caught and corrected in baseline register by 2026-05-05, before any CISA/FBI transmission. Note on provenance: the ZOMBIE-ASN-REGISTRY.db source_ref for this entry (FALSE-POSITIVE-ALERT-AS6181-CISA-SUPPLEMENT-VRF26-04-TPWXX.txt) is an internal Backwater Forensics record documenting the correction — despite the filename, it was never transmitted to CISA. Timing meant AS6181 was already resolved before any CISA filing cycle that would have included it; neither the original zombie characterization nor the correction record ever left this investigation. See correction note below.
| Date | File | Type |
| 2026-05-03 | prefixes_AS6181_20260503_170109.json | Level 5 — BGP/Prefix |
| 2026-05-03 | sample_ips_AS6181_20260503_170109.txt | Level 5 — BGP/Prefix |
| 2026-05-08 | pdns_AS6181_20260508_193449.json | Level 3 — Passive DNS |
| 2026-06-18 | rdap-batch-20260618_024735.txt [shared: multi-ASN] | Level 5 — BGP/Prefix (RIPEstat routing-status; confirms AS6181 live/active, 116 prefixes) |
| 2026-07-12 | AS6181-DEETS.txt | Level 4 — RDAP/WHOIS (registrant confirmation). Direct rdap.arin.net/registry/autnum/6181 pull. Registrant: Cincinnati Bell Telephone Company LLC (CBTL-6). Resolves the AS6181 attribution conflict definitively. |
AS7015 — COMCAST-7015 — Comcast-operated TCI legacy, 159 downstream customers
Status: ZOMBIE_TRANSIT (Tier R, 2026-05-05) → SINKHOLE_TRANSIT (Tier R — corrected; not Tier A) | Case ref: CASE-002/003 | Confidence tier: R | Evidence files: 13
Corrected from an earlier draft: this was previously written as “Tier A, FBI seizure/sinkholing” — overstated. The 2026-05-05 baseline (Tier R: pDNS, RDAP, BGP) identified AS7015 as ZOMBIE_TRANSIT. BACKBONE-INVESTIGATION-LOG-v2.md (I-032) and ZOMBIE-ASN-REGISTRY.db document a status change to SINKHOLE_TRANSIT, with the registry’s own language describing this as “likely law enforcement infrastructure (INTERPOL/FBI)” based on dark-window timing coinciding with INTERPOL Operation Ramz (~2026-05-19/22) — an assessment, not a confirmed seizure. Held at Tier R per Section 3.2/3.4; see 8.1a.
| Date | File | Type |
| 2026-05-05 | bgp_announced_AS7015_20260505_034213.txt | Level 5 — BGP/Prefix |
| 2026-05-05 | bgp_neighbors_AS7015_20260505_034115.txt | Level 5 — BGP/Prefix |
| 2026-05-05 | bgp_neighbors_AS7015_20260505_034128.txt | Level 5 — BGP/Prefix |
| 2026-05-05 | bgp_routing_history_AS7015_20260505_034008.txt | Level 5 — BGP/Prefix |
| 2026-05-05 | dns_AS7015_intl_20260505_020656.txt | Level 3 — DNS/PTR check |
| 2026-05-05 | prefixes_AS7015_20260505_010528.json | Level 5 — BGP/Prefix |
| 2026-05-05 | sample_ips_AS7015_20260505_010528.txt | Level 5 — BGP/Prefix |
| 2026-05-05 | whois_AS7015_intl_20260505.txt | Level 4 — RDAP/WHOIS |
| 2026-05-05 | whois_apnic_AS7015_20260505.txt | Level 4 — RDAP/WHOIS |
| 2026-05-05 | whois_arin_AS7015_20260505.txt | Level 4 — RDAP/WHOIS |
| 2026-05-08 | pdns_AS7015_20260508_174745.json | Level 3 — Passive DNS |
| 2026-05-05 | BLOCK 3-4 — BONUS- AS7015-8069.txt [shared: AS8069] | Analyst synthesis |
| 2026-05-05 | bgp_path_AS7015_intl_batch.txt | Level 5 — BGP/Prefix |
AS7029 — Windstream Communications LLC
Status: WINDSTREAM_RECLAIM | Case ref: CASE-010 | Confidence tier: R | Evidence files: 7
Prior CONTROL_LOST characterization retracted (CISA CORRECTION log UPDATE-002).
Not yet verified — correction to a prior draft (2026-08-18): an earlier version of this note claimed this association was “confirmed via live RDAP check, 2026-07-15.” That claim was made without a saved artifact to support it and has been retracted. The full rdap-batch-20260506_022253.txt batch (8 blocks: AS6478, AS7922, AS8069, AS7132, AS20115, AS5650, AS10913, AS7029) was checked directly and confirmed to contain only ASN-level registrant lookups — no query on 154.194.16.0/21 or any block-level record appears anywhere in it. The LARUS-SERVICE-MNT/Cloud Innovation Ltd association on 154.194.16.0/21 — the second half of Section 4.1’s cross-ASN signature — remains documented only in CISA-CORRECTION-AGGREGATE-VRF26-04-TPWXX.md [NEW-001], with no independent block-level RDAP confirmation on file. asn_source.json‘s silence on this block is a thin watchlist config, not a full analytic record, so it isn’t treated as a contradiction — but this needs a direct RDAP query on 154.194.16.0/21, likely via AFRINIC (Cloud Innovation Ltd is a Seychelles/AFRINIC secondary-market registrant, outside ARIN’s authoritative region), before Section 4.1 can rely on it as a second confirmed instance. Not yet resolved either direction.
| Date | File | Type |
| 2026-05-05 | dns_AS7029_state_change_20260505_020107.txt | Level 3 — DNS/PTR check |
| 2026-05-05 | prefixes_AS7029_20260505_012337.json | Level 5 — BGP/Prefix |
| 2026-05-05 | prefixes_AS7029_20260505_015744.json | Level 5 — BGP/Prefix |
| 2026-05-05 | sample_ips_AS7029_20260505_012337.txt | Level 5 — BGP/Prefix |
| 2026-05-05 | sample_ips_AS7029_20260505_015744.txt | Level 5 — BGP/Prefix |
| 2026-05-08 | pdns_AS7029_20260508_192335.json | Level 3 — Passive DNS |
| 2026-05-08 | pdns_AS7029_20260508_193215.json | Level 3 — Passive DNS |
AS10913 — INTERNAP-BLK / Unitas Global (EarthLink successor)
Status: LEGITIMATE_SUCCESSOR | Case ref: CASE-010 | Confidence tier: R | Evidence files: 10
Formal retraction on file: CISA CORRECTION-002. Originally filed TRUE ZOMBIE (2026-05-02 supplemental); revised and retracted 2026-05-05 after Phase C confirmed Unitas Global as legitimate successor.
| Date | File | Type |
| 2026-05-03 | prefixes_AS10913_20260503_170109.json | Level 5 — BGP/Prefix |
| 2026-05-03 | sample_ips_AS10913_20260503_170109.txt | Level 5 — BGP/Prefix |
| 2026-05-05 | prefixes_AS10913_20260505_012337.json | Level 5 — BGP/Prefix |
| 2026-05-05 | prefixes_AS10913_20260505_015744.json | Level 5 — BGP/Prefix |
| 2026-05-05 | sample_ips_AS10913_20260505_012337.txt | Level 5 — BGP/Prefix |
| 2026-05-05 | sample_ips_AS10913_20260505_015744.txt | Level 5 — BGP/Prefix |
| 2026-05-05 | whois_arin_AS10913_20260505.txt | Level 4 — RDAP/WHOIS |
| 2026-05-08 | pdns_AS10913_20260508_192335.json | Level 3 — Passive DNS |
| 2026-05-08 | pdns_AS10913_20260508_193215.json | Level 3 — Passive DNS |
| 2026-05-05 | prefixes_AS10913_survived.txt | Level 5 — BGP/Prefix |
AS11427 — TWC-11427-TEXAS — Charter ARIN, BGP operator unknown
Status: THIRD_PARTY_CONTROL | Case ref: CASE-001 | Confidence tier: R | Evidence files: 8
Formal correction on file: CISA CORRECTION-001. Zone anchor status; Cloud Innovation Ltd / LARUS-SERVICE-MNT secondary-market pattern (see NEW-001, cross-referenced with AS7029).
| Date | File | Type |
| 2026-05-05 | dns_AS11427_state_change_20260505_020451.txt | Level 3 — DNS/PTR check |
| 2026-05-05 | prefixes_AS11427_20260505_012337.json | Level 5 — BGP/Prefix |
| 2026-05-05 | prefixes_AS11427_20260505_015744.json | Level 5 — BGP/Prefix |
| 2026-05-05 | sample_ips_AS11427_20260505_012337.txt | Level 5 — BGP/Prefix |
| 2026-05-05 | sample_ips_AS11427_20260505_015744.txt | Level 5 — BGP/Prefix |
| 2026-05-05 | whois_arin_156x_AS11427_20260505.txt | Level 4 — RDAP/WHOIS |
| 2026-05-05 | whois_arin_AS11427_20260505.txt | Level 4 — RDAP/WHOIS |
| 2026-05-08 | pdns_AS11427_20260508_174745.json | Level 3 — Passive DNS |
AS7046 — RFC2270-UUNET-CUSTOMER (Verizon Business / MCICS)
Status: SINKHOLE_FEDERAL → UNREMEDIATED_VULNERABLE — recurring unauthorized occupation, LE activity observed but not confirmed as ongoing | Case ref: CASE-005 (WorldCom/MCI/UUNET lineage) | Confidence tier: R (RDAP + BGP; not independently Tier A — see note) | Evidence files: 13
Relabeled from SINKHOLE_FEDERAL. That status implied a stable, ongoing federal operation. The evidence supports something narrower and more durable: the address-space stewardship gap (unauthorized originas, unvalidated POC) has never been closed, and disruption of one occupant (coincident with INTERPOL Operation Ramz, ~2026-05-19/22) did not remediate the underlying condition — the space was reoccupied by 2026-06-16, and again by 2026-07-15 using a different block. Whether any of the three periods involved the same actor, a different criminal occupant, or genuine law enforcement activity is not established by RDAP/pDNS alone. What is established is the vulnerability’s persistence across at least three independent observation windows spanning two months.
Tier R confirmed via RDAP originas check: five IPv6 blocks — WIRE-V6, TERRENAP-V6, CFTC-NETWORK, DOLNET, and CMMS-IPV6 (newly identified, not present in the 2026-05-05 prefix list) — all return originas: [], meaning no ASN, including the one currently announcing them, carries documented authorization. Re-confirmed via direct RDAP query 2026-07-15 (all five same-day, no stale data). CMMS-IPV6’s registrant (CMMS-4) is a name match consistent with Centers for Medicare & Medicaid Services but is not independently verified beyond that match; this paper does not assert that identification as confirmed. Corroborated by BGP dark-window behavior (dark 2026-05-19, coincident with INTERPOL Operation Ramz; re-emerged 2026-05-20, stabilized 2026-05-22) and technical POC (OA12-ARIN) unvalidated since 2022-11-02, confirmed unchanged as of 2026-07-15.
Cross-ASN claim ruled out. A prior registry note suggested the CFTC-NETWORK block (2620:0:250::/48) also appeared in AS11427. Direct RIPEstat check of AS11427’s full IPv6 prefix list (2026-07-14) shows this is not the case — the two ASNs’ IPv6 space is entirely disjoint. This does not go into Section 4.1’s cross-ASN pattern discussion; it was checked and did not hold up.
External corroboration of carrier identity (added 2026-07-30). Nemmi et al. (2021), independent of this investigation, document AS7046 in an unrelated case study (Section 6.4, “Unallocated ASNs used internally leak to the global Internet”): an unallocated ASN (AS290012147) announced a covered /24 for over two years (2015–2017), with the observed AS path forming the triplet {AS290012147, AS7046, AS701}. The authors state both AS701 and AS7046 were held by Verizon at the time, and attribute the leak to an internal Verizon misconfiguration — not third-party occupation. This is a different phenomenon from this investigation’s finding (a 2015–2017 internal routing leak vs. this paper’s 2026 unauthorized-originas stewardship gap) and is not evidence of the current vulnerability. What it does establish, independently of this investigation and pre-dating it by roughly a decade: Verizon is confirmed, from an external academic source, as the carrier that held and operated AS7046 — reinforcing that Verizon is the party whose stewardship lapsed, not a disputed or ambiguous attribution.
bybanking.com — two independent blocks, two months apart. Tier 3 pDNS (2026-06-16): subdomain 9ve2e267.bybanking.com resolves to 161.162.17.104 in 161.162.17.0/24. A second pDNS run (2026-07-15): ns-5whj.bybanking.com resolves to 198.57.13.170 in 198.57.13.0/24 — a different subdomain, IP, and /24 entirely. Both blocks independently confirmed as genuinely announced by AS7046 via direct RIPEstat prefix-list query, not inferred from the pDNS tool’s internal sampling. Two independently-confirmed hosting blocks two months apart is a persistent pattern, not a single stale record.
Falcon Sandbox — six analyses now. The Feb 9, 2026 report (analysis 6989f42c…, third-party/pre-existing, found via search) shows bybanking.com resolving to 148.17.131.206 (US), threat score 45/100, 1 domain/3 hosts contacted, TTL-5 fast-flux. A second analysis (6a31af53…) was submitted 2026-06-16 by this investigation directly — a deliberate exception to the standing sandbox-resubmission protocol, made to answer a specific question the Feb report couldn’t: whether the block showed signs of reactivating, and if so, in what form (continued sinkhole/honeypot use vs. genuine criminal reoccupation). Results differed meaningfully: bybanking.com resolved to 45.145.86.142 (United Kingdom, not the US), 11 domains/18 hosts contacted, active HTTP traffic and Suricata alerts present, and a different OS/browser sandbox environment (Windows 11/Chrome vs. Windows 10/Edge).
Two further analyses were submitted 2026-07-15, same investigation account, same deliberate-exception rationale: a Windows 11 run (6a56f6183bcc…, 02:53 UTC) with bybanking.com resolving to 175.232.34.31 (South Korea), and a Windows 10 run (6a56fdb39723…, 03:25 UTC, 32 minutes later) resolving to 101.98.55.5 (New Zealand) — a different country in each of four checks now (US → UK → South Korea → New Zealand), the tightest rotation window observed to date. Both July reports carry Hybrid Analysis’s own automated warning that the verdict (“no specific threat”) does not match other analyses of the same file hash and may be outdated — notable because both July runs detected *more* indicators than the earlier ones (16–17, plus a new Suricata alert category) while receiving a *lower* threat classification than the Feb/Jun “suspicious” verdicts. This inconsistency is recorded here as observed, not resolved; it is not this paper’s place to arbitrate between Hybrid Analysis’s own scoring runs.
Two more analyses were submitted 2026-07-25, 35 seconds apart, both crossing into “malicious” verdict territory for the first time (prior verdicts topped out at “suspicious”): a Windows 11 run (6a640572395a8786460e0c4c…, 00:38:11 UTC, threat score 76/100) resolving to 123.150.3.39 (China), and a Windows 10 run (6a64054fcf58877fc3076b10…, 00:37:36 UTC, threat score 70/100) resolving to 145.74.110.172 (Netherlands). Both carry a new “Malicious domain detected” indicator and cookie-theft behavior (“Attempts to retrieve cookies from browser memory,” “Able to access web session cookie”) not present in earlier runs — a genuine behavioral escalation, independent of the threat-score trend, which is also consistent with the general pattern of reputation-platform scores climbing as a known-bad domain accumulates detection history rather than necessarily reflecting a real-time change in the infrastructure itself.
The China-resolving block was directly checked against AS7046 and is not part of it. Live RIPEstat query (2026-07-26) against AS7046’s full IPv4 prefix list confirms 123.150.3.39 does not fall within any AS7046-announced block. This is the first confirmed instance of bybanking.com resolving entirely outside AS7046’s address space. What this does and does not establish: it confirms the *domain* has moved off this particular zombie ASN; it does not by itself establish that AS7046’s underlying stewardship gap (the originas: [] condition documented above) has been remediated — those are separate questions, and only the first has been directly tested. The Netherlands-resolving IP (145.74.110.172) has not yet been checked against AS7046’s current prefix list.
On attribution: HA’s country tagging for the China- and Netherlands-resolving IPs establishes hosting location only, not operator identity. Leased, compromised, or bulletproof-hosting infrastructure in either location would produce the same geolocation signal regardless of who is actually operating the campaign. This paper does not assert an operator location beyond what is directly supported.
This is disclosed here for transparency: all five post-Feb submissions are investigation-generated evidence, not discovered third-party data, and all post-date this investigation’s own Tier R sinkhole confirmation (2026-05-27).
Current routing state (re-confirmed 2026-07-14/15): 220 IPv4 prefixes, 24 IPv6 prefixes, 100% RIS visibility (326/326 IPv4 peers, 321/321 IPv6 peers), last seen 2026-07-14T16:00:00. Not dark, not dormant — fully visible in global BGP routing as of this writing.
What this does not establish (per the source finding’s own limits, carried forward under the actor-agnostic framing in Section 2.3): the specific federal agency operating the sinkhole; the identity of the threat actors whose callbacks are being captured; whether the Hong Kong contact (63.222.23.49, Feb report) is part of the same operation; whether routing here reflects formal seizure, informal sinkhole arrangement, or continued unauthorized third-party control unrelated to law enforcement.
Reporting status — corrected. The original source finding claimed AS7046 was “reported to CISA + FBI 2026-05-02.” Direct text search of the actual filed 2026-05-02 CISA supplemental and both versions of the correction aggregate log confirms zero mentions of AS7046 in any of them — and the claim is chronologically impossible regardless, since AS7046 wasn’t a named candidate in this investigation’s own batch planning until after that date, and its Tier R confirmation didn’t occur until 2026-05-27. The finding was actually transmitted via IC3 on 2026-07-16.
Reporting delay — flagged as a process concern, not minimized. The bybanking.com C2 finding was discovered 2026-06-16 and not actually reported until 2026-07-16 — exactly 30 days. The proximate cause is on record: the 2026-06-16 finding document’s own “Report Status” section stated AS7046 had already been reported on 2026-05-02 and that “no additional disclosure action is required.” That belief was false, but nothing tested it until this paper’s drafting process independently swept the actual CISA filings weeks later and found no record of it. For an active banking-malware C2 domain, a documentation error that goes unchecked for 30 days is not a minor bookkeeping issue — it is 30 days the domain continued operating unflagged to any external party who could act on it. This is logged here as a concrete illustration of the broader methodological point already made elsewhere in this paper (Section 2.5’s “cleared findings are retained” principle, and the AS10913/AS6181 cases): an unverified claim about disclosure status is itself a finding that needs the same evidentiary discipline as any other, and this is the one case in this investigation where that discipline was applied too late to prevent real-world consequence.
| Date | File | Type |
| 2026-02-09 | Falcon Sandbox report, bybanking-february-2026.pdf (analysis 6989f42c…) | Third-party OSINT — pre-existing, found via search |
| 2026-05-27 | RDAP originas batch — 7046–confirmed–FF.txt (raw RDAP queries, primary source) | Level 4 — RDAP/WHOIS |
| 2026-06-16 | BIV-ANO-2026-06-16_AS7046-PDNS-BYBANKING.md | Level 3 — Passive DNS + analyst synthesis |
| 2026-06-16 | Falcon Sandbox report, bybanking-june-2026.pdf (analysis 6a31af53…) | Investigation-submitted — deliberate reactivation check, not third-party OSINT |
| 2026-06-16 | BIV-PND-2026-06-16_SESSION-PAUSE-STATE.md | Session state / procedural record |
| 2026-07-15 | Second pDNS finding — 198.57.13.0/24, ns-5whj.bybanking.com | Level 3 — Passive DNS |
| 2026-07-14/15 | Live re-confirmation — RDAP (5 blocks), RIPEstat routing-status, ASN-level RDAP, AS11427 cross-check | Level 4/5 — RDAP + BGP, current as of filing |
| 2026-07-15 | Falcon Sandbox report, bybanking-july-2026-win11.pdf (analysis 6a56f6183bcc…, 02:53 UTC) | Investigation-submitted — reactivation check |
| 2026-07-15 | Falcon Sandbox report, bybanking-july-2026-win10.pdf (analysis 6a56fdb39723…, 03:25 UTC) | Investigation-submitted — reactivation check |
| 2026-07-15 | CISA-FBI-INITIAL-AS7046-BYBANKING-2026-07-15.txt | Drafted disclosure filing, superseded the earlier CISA-SUPPLEMENTAL-… draft. |
| 2026-07-16 | IC3 filing confirmation, Submission ID 1ac64da023d24387bc4e6dd811b8c456 | Transmitted. 30 days after the underlying finding (2026-06-16). See reporting-delay note above. |
| 2026-07-25 | Falcon Sandbox report, HA-072726-bybanking-dot-com-W11.pdf (analysis 6a640572395a8786460e0c4c, 00:38:11 UTC) | Investigation-submitted — first “malicious” verdict (76/100), resolved to China |
| 2026-07-25 | Falcon Sandbox report, HA-072726-bybanking-dot-com-W10.pdf (analysis 6a64054fcf58877fc3076b10, 00:37:36 UTC) | Investigation-submitted — 70/100 malicious, resolved to Netherlands |
| 2026-07-26 | Live RIPEstat check — 123.150.3.39 confirmed not in AS7046’s announced IPv4 space | Level 5 — BGP/Prefix, current as of filing |
| 2026-06-18 | SNAP-BASELINE-20260618.md | Level 5 — BGP/Prefix (change-detection baseline, includes AS6128 cross-reference) |
8.1c Summarized Evidence — Non-Load-Bearing ASNs
The following ASNs are cleared/stable with no open questions; most are not individually discussed in the narrative beyond their appearance in Table 4.1 (Section 4.2) or as baseline, comparison, or control entries. Full per-file evidence tables have been condensed to one row each; raw filenames and per-file hashes remain in SHADOW_MARKET_FILE_HASHES.txt regardless of this summarization.
| ASN | Entity | Status | Case ref | Files | Role / Note |
| AS209 | CenturyLink/Lumen — Qwest/Embarq successor | LEGITIMATE_SUCCESSOR | CASE-007 | 4 | Baseline |
| AS701 | UUNET / Verizon Business — MCI successor | LEGITIMATE_SUCCESSOR | CASE-005 | 10 | Comparison/control (paired run with AS3549). *Handoff reference table flags a “CISA correction UPDATE-003” tie for this ASN — not present in this paper’s draft text or in SHADOW_MARKET_FILE_HASHES.txt. Unverified; flagged for analyst confirmation, not asserted here.* |
| AS702 | UUNET-AS702 / Verizon Business legacy | LEGITIMATE_SUCCESSOR | CASE-005 | 2 | Comparison/control |
| AS2686 | ATGS-MMD-AS — AT&T Enterprises LLC | MISATTRIBUTION → LEGITIMATE_SUCCESSOR | CASE-007 | 1 | Comparison/control; prior working assumption (Sprint-FL/Embarq) corrected via RDAP+RIPEstat |
| AS3549 | Lumen / Level 3 — Global Crossing successor | LEGITIMATE_SUCCESSOR | CASE-004 | 10 | Paired run with AS701. *Same unverified UPDATE-003 reference as AS701 above — see note.* |
| AS5650 | FRONTIER-FRTR — Frontier Communications | MISATTRIBUTION | CASE-007 | 1 | Comparison/control; prior working assumption (Embarq Corp) corrected |
| AS6128 | Cablevision Systems (Altice retained) | RETENTION_ANOMALY | CASE-009 | 4 | Baseline |
| AS6478 | TCI/@Home (collapsed 2001, properly retired) | CLEAN | CASE-003 | 4 | Baseline |
| AS7132 | SBIS-AS / SBC Internet Services / Ameritech backbone | CLEAN | CASE-006 | 1 | Baseline |
| AS7922 | COMCAST-7922 (post-TCI production ASN) | CLEAN | CASE-002/003 | 3 | Baseline |
| AS8069 | Microsoft Corp — misattributed to Ameritech | MISATTRIBUTION / ACTIVE_MONITOR? — unresolved source conflict | CASE-006 | 6 | Cited in Table 4.1 (Section 4.2) as its own disposition row — status conflict, not cleared, not independently resolved. Open item, carried forward, not silently resolved: ZOMBIE-ASN-REGISTRY.db shows escalation to ACTIVE_MONITOR (2026-05-12); asn_source.json (documented source of truth) shows MISATTRIBUTION, frozen 2026-05-06, and has no ACTIVE_MONITOR value in its schema. PeeringDB confirms AS8069 as Microsoft Azure Routing Preference regardless of which status label is current. |
| AS10796 | TWC-10796-MIDWEST (Charter retained, clean) | CLEAN | CASE-008 | 2 | Baseline |
| AS11426 | TWC-11426-CAROLINAS (Charter dual-ASN retention) | RETENTION_ANOMALY | CASE-001 | 3 | Baseline |
| AS14905 | CENTURYLINK-LEGACY-EMBARQ-VACHVL | LEGITIMATE_SUCCESSOR | CASE-007 | 1 | Comparison/control |
| AS20115 | Charter/Spectrum (production ASN) | CLEAN | CASE-001 | 1 | Baseline |
| AS33363 | BHN-33363 — attribution conflict (Adelphia vs. BHN) | PENDING_VERIFICATION → RETENTION_ANOMALY (confirmed 2026-05-07) | CASE-002 | 6 | Corrected, not cited in Section 4. Live recheck (2026-07-15): registrant/status unchanged; prefix count 494→436 (12% decline since baseline), cause open — no baseline total-IP figure on file to distinguish genuine shrinkage from routine aggregation. Logged CHG_DETECTED, not resolved either direction. |
| AS36727 | Insight Communications (post-acquisition clean) | CLEAN | CASE-008 | 3 | Baseline |
| AS54396 | Nuance Communications (small ASN, misattributed to Altice’s cable ASN) | CLEAN → MISATTRIBUTION | CASE-009 | 1 | Corrected, not cited in Section 4. ARIN name is NUANCE-MOBILITY, 1 active prefix; AS6128 remains Altice’s actual cable ASN for CASE-009. |
Subtotal, summarized ASNs: 18 ASNs, 63 evidence files.
8.2 Multi-ASN / Batch Evidence
*Cull review: reviewed during the 2026-07-29 evidence cull and kept as-is — already condensed to type/count/date-range on a prior pass; no further trimming warranted.*
Files not attributable to a single ASN — BGP watchlist monitor runs, batch DNS/pDNS sweeps, and multi-ASN RDAP/registration analyses. Cross-referenced under each relevant ASN above where applicable (e.g., the AS701/AS3549 RDAP analysis and the AS7015/AS8069 synthesis document each appear once here in aggregate and once under their respective ASN sections above). Summarized by type rather than listed individually; raw filenames and per-file hashes remain in SHADOW_MARKET_FILE_HASHES.txt.
| Type of Data Run | Number of Runs | Date Range |
| BGP watchlist monitor (zombie_report) | 42 | 2026-05-03 – 2026-05-20 |
| DNS/PTR check (dns_check_batch) | 12 | 2026-05-03 – 2026-05-04 |
| pDNS run log (pdns_run) | 11 | 2026-05-08 – 2026-05-09 |
| pDNS summary (pdns_summary) | 11 | 2026-05-08 – 2026-05-09 |
| RDAP/WHOIS (multi-ASN) | 6 | 2026-05-05 – 2026-05-06 |
| Procedural/command log | 4 (incl. 5-4-26-zombie-hunter-TerminalOutput.txt, renamed from Terminal Saved Output.txt; terminal-may5.txt) | 2026-05-04 – 2026-05-05 |
| Other (incl. setiii-rdap-arin.txt) | 3 | 2026-05-03 – 2026-05-06 |
| Analyst synthesis, multi-ASN (BLOCK 3-4) | 1 | 2026-05-05 |
| BGP/Prefix, multi-ASN | 1 | 2026-05-05 |
| Total, batch/multi-ASN evidence | 91 | 2026-05-03 – 2026-05-20 |
8.3 Supporting Case Documents (Session-Provided, Not Per-ASN Evidence)
Working documents used to reconcile the evidence base and resolve the AS6181/AS2686 corrections. Retained for chain-of-custody completeness; not attributable to a single ASN.
| Date | File | Role |
| 2026-05-02 | CISA-SUPPLEMENTAL-ZOMBIE-BGP-2026-05-02.txt | The actual filed CISA supplemental report. Confirmed AS6181 was never included in this filing (swept for “6181”, “AS702”, “5650”, “14905” — no genuine matches). |
| 2026-05-02 | phase_a_candidates_20260502_011511.csv | Phase A national survey scoring output; source of the original (later corrected) AS6181/Insight zombie-BGP flag. |
| 2026-05-08 | PDNS-BATCH-QUEUE.txt | Batch run plan confirming AS702/AS2686/AS5650/AS14905 were planned, in-scope candidates (Batches C–E), not cross-case artifacts. |
| 2026-05-07 to 2026-05-19 | BACKBONE-INVESTIGATION-LOG-v2.md | Working investigation log; source for registry expansion (I-027, 20→23 ASNs) and the AS7015 post-05-19 status question flagged in the AS7015 entry above. |
*Backwater Forensics | Lu Anne Esposito, MS Digital Forensic Science | Draft — 2026-07-09*
